Heavy Duty Castors

In relation to mass and weight, modern heavy industry often thinks in dimensions that are a feat of strength for people and machines. For example, take a passenger bridge for the harbour, construction machines for road building, etc. All these heavy weights need to be moved. You’ll be doing well if you deal with these tasks on super-stable heavy load castors from Colson. Because in materials quality and processing, they are the absolute master in their class. This you can depend upon.

JSPB 0802 5000 80 mm - 125 mm, 150 kg - 200 kg

Technical data

Diameter 80 mm
Wheel width 35 mm
Hub length 45 mm
Height 110 mm
Offset 40 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 120 mm
Load capacity 150 kg
Weight 1 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with one deep groove ball bearing

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel

JSPB 0802 5000/B 80 mm - 125 mm, 150 kg - 200 kg

Technical data

Diameter 80 mm
Wheel width 35 mm
Hub length 45 mm
Height 110 mm
Offset 40 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 120 mm
Load capacity 150 kg
Weight 1.2 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with one deep groove ball bearing

Technical description

  • Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
  • ball bearing and a grease nippel
