Medical Equipment Castors

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from Colson are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

BWCU 1253 6040
BWCU 1253 6040


100 mm - 300 mm, 250 kg - 1800 kg

Technical data

Diameter 125 mm
Wheel width 40 mm
Height 175 mm
Offset 45 mm
Top plate dimensions 135x110 mm
Top plate hole diameter 13 mm
Dist. between holes 105x80 mm
Load capacity 400 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with bonded-on polyurethane tyre (Shore A 92) with two taper roller bearings

Technical description

  • Heavy duty swivel fork for dual wheels, in extra thick pressed and welded steel. With a tapered roller bearing in the swivel head, black lacquered.
BWCU 1253 60402
BWCU 1253 60402


125 mm - 250 mm, 600 kg - 2800 kg

Technical data

Diameter 125 mm
Wheel width 2x40 mm
Height 197 mm
Offset 60 mm
Top plate dimensions 170x170 mm
Top plate hole diameter 13 mm
Dist. between holes 130x130 mm
Load capacity 750 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with bonded-on polyurethane tyre (Shore A 92) with two taper roller bearings

Technical description

  • Heavy duty swivel fork for dual wheels, in extra thick pressed and welded steel. With total lock brake and a tapered roller bearing in the swivel head. Black lacquered.
