TFH200PT2H
TFH200PT2H 200 mm, 1100 kg
Technical data
| Diameter | 200 mm |
| Tread width | 45 mm |
| Height | 252 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 1100 kg |
TFH250PT2H
TFH250PT2H 250 mm, 1200 kg
Technical data
| Diameter | 250 mm |
| Tread width | 45 mm |
| Height | 303 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 1200 kg |
TFH300PT2H
TFH300PT2H 300 mm, 1400 kg
Technical data
| Diameter | 300 mm |
| Tread width | 45 mm |
| Height | 353 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/78 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 1400 kg |
TSH100PT2H
TSH100PT2H 100 mm, 340 kg
Technical data
| Diameter | 100 mm |
| Tread width | 38 mm |
| Height | 152 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 340 kg |
TSH100PT2HD
TSH100PT2HD 100 mm, 340 kg
Technical data
| Diameter | 100 mm |
| Tread width | 38 mm |
| Height | 152 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 340 kg |
TSH125PT2H
TSH125PT2H 125 mm, 340 kg
Technical data
| Diameter | 125 mm |
| Tread width | 38 mm |
| Height | 177 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 340 kg |
TSH125PT2HD
TSH125PT2HD 125 mm, 425 kg
Technical data
| Diameter | 125 mm |
| Tread width | 38 mm |
| Height | 177 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 425 kg |
TSH125PT2HF
TSH125PT2HF 125 mm, 425 kg
Technical data
| Diameter | 125 mm |
| Tread width | 38 mm |
| Height | 177 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 425 kg |
TSH150PT2H
TSH150PT2H 150 mm, 730 kg
Technical data
| Diameter | 150 mm |
| Tread width | 38 mm |
| Height | 202 mm |
| Top plate dimensions | 150X110 mm |
| Top plate hole diameter | 10 mm |
| Dist. between holes | 120X60, 105X80/75 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 730 kg |
